G200 is a laser stabilisation platform that combines line-lock and offset-lock control in a compact package. Available as a complete instrument or as OEM subsystems, it provides stable, programmable laser frequencies from an atomic reference and is designed for compact quantum and photonics systems.
| Parameter | Value |
|---|---|
| Operating Wavelength | 780nm (795nm on request) |
| Typical Configuration | 1x Line lock, 2x Offset lock |
| Reference Medium | Rubidium Vapor Cell |
| Offset-lock detuning range | +/- 100 MHz to 6.8 GHz |
| Output Power | 90 mW Per Channel |
| Output interface | Polarization Maintaining Optical Fiber |
| Control And Monitoring | Embedded Control PC with software Interface |
| Form Factor | 3U 19 inch rack enclosure |
