In Stock
Data acquisition cards S310

Multifunction DAQ I/O Module, 24-bit precision acquisition

$1,195
- +

S310 DAQ PC-104 (PCI) 24 bit Analog Input (16SE/8DI), 16 bit Analog Output (8), 48 DIO
Redwave Labs Ltd S310 DAQ provides all necessary functions for high precision measurement and control: 24 bit Analog Input channels (16 SE or 8 DI, -10 to+10V), 1.12 kS/s; Programmable Gain Amplifier (PGA) from 0.125 to 128; 16 bit Analog Output, 1.12kHz max update rate (8 channels, -10 to +10V and -5to +5V); 48 DIO with high output capacity (20 mA per channel); DSP (TI DM6437 4800 MIPS) and user space of 64kB of memory; on board temperature and high precision voltage references.
